Burst Bags Explained: Middle-seal Bulge and End-seal Tear Have Opposite Causes
Does the bag bulge at the middle seal or tear at the end seal? The causes are nearly opposite - adjust the wrong way and it gets worse. Per the manual: a middle-seal bulge is often too hot, too much silicone oil, or over-inflation, so lower the middle-seal temp and use less oil; an end-seal tear is often too cold or uneven jaws, so raise the end-seal temp and re-level them. Also how the front/rear sponge on top vs bottom sets inflation or venting.
-
Temp Controller Shows --- or Jumping? 3 Tests to Tell Thermocouple from SSR
Blank display or jumping temps? Do not replace the whole part. Per the manual fault table: a --- readout usually means the thermocouple loop is open (no signal); runaway heating means the SSR is welded shut; power off and measure the heater with a multimeter - infinite ohms means burned, near zero means short. Also check loose terminals and over/volatile voltage. Rule: always cut power and use a qualified electrician.
-
Horizontal (End) Seal Leaks? 4 Steps Before You Touch the Temperature
End seal leaks or tears? Operators usually reach for the temperature first - the longest detour. Per the manual fault table, go four steps: stop, cool, scrub the end-seal jaw with a wire brush dipped in silicone oil (dirty jaw is the #1 cause); check jaw misalignment and re-align; only then set temperature (0-399C, tune until both seals hold without leaking or wrinkling); lastly change poor film. This order fixes most failures on the spot.
-
Half-Year “Heart Check”: Don't Let PCB Dust Burn Your PLC
The PLC and circuit boards are the heart of the machine, yet untouched for half a year. Dust layers and loose terminals lead to overheating, tracking in damp weather, and arcing — the fault table lists a loose terminal as a cause of a blank temp controller. Per the manual: every half year check the terminal block and tighten loose wires, and blow dust and dirt off the components and PCBs with clean, dry compressed air. Always cut the power first; never work live; use a qualified electrician.
-
Bearings, Chains, Belts: the Feel-Look-Listen Diagnosis for VFFS Drives
Heating, sealing and film pulling are visible, but what really runs a vertical packaging machine are the bearings, chains and belts behind the panels. They fail in order: first noise, then vibration, then a sudden stop. This guide gives the feel-look-listen diagnosis (temperature, tension, wear, sounds), the manual's 4 monthly tasks — lubricate end-seal bearings, lubricate drive chains/sprockets, tension chains and belts, tighten loose screws — plus a belt wear checklist.
-
Burnt Residue on the Seal Jaw: How It Ruins Your Bags (Wire-Brush Tips)
A weak horizontal seal makes operators reach for the thermostat first. More often it is a dirty jaw: the hot end-seal jaws stick to the film, and repeated film scraps scorch into a dark hard crust that ruins heat transfer and makes bags leak, burst at the side, or tear at the end. The manual's fix is simple — after cooling, brush the jaw with a wire brush dipped in silicone oil, which both cleans and prevents re-sticking. A before/after comparison and three wire-brush tips are included.
-
Stop ≠ Power Off: The VFFS Daily 30-Minute Maintenance Checklist
Stopping is not maintenance. Per manual 6.1, clean after every run: first cut power and let heaters cool. Then blow line debris with compressed air, brush film scraps off the side/end seal jaws with a silicone-oil wire brush, wipe panels and guards, and clean the photoeye lens and tension roller. Three don'ts: never spray water/vapor on it, never clean before it cools, never use alcohol on painted surfaces. Daily checklist included.
-
VFFS Thermal Transfer Ribbon Broken? 3 Fixes Before You Throw It Away
Ribbon broken or mark faint? Before swapping it, check the manual's 3 adjustment points. Print pressure is set by the air-cylinder inlet: too low = faint mark, too high = punched film and a crushed ribbon. The slide-block date position must be locked, or vibration drifts it and tears the ribbon. When changing ribbon, remove parts 4&5, thread per the diagram, then fix the end cap. A pressure-vs-print table is included to extend ribbon life.
-
Why Does Your Registration Eye Keep Alarming? The Print Design May Be at Fault
A new print design goes on the machine and the screen keeps flashing “registration eye fault” with automatic stop. Sensor untouched, sensitivity unadjusted, bag length correct — the problem is in the design itself. The manual requires a clean 10mm edge zone and clear contrast between mark and base. This guide gives a 5-point design checklist, the correct troubleshooting order (mark first, distance second, sensitivity last), and a warning that strong light makes the eye fail
-
Buying Packaging Film by Thickness Alone? 3 Hidden Specs That Cost You Money
Ordering film with only a thickness spec? The roll arrives and the core hole does not fit the mandrel — the whole roll is returned. The manual defines three hidden specs: outer diameter ≤300mm, core inner diameter 75mm, thickness 0.05-0.08mm, plus a clean 10mm edge zone with high-contrast registration marks. This guide explains why each spec matters (mandrel fit, film path, electric-eye scanning), gives an order-ready checklist, and a receiving inspection procedure.
-
Bag Former Skew? Master the 2mm "Life Line" for Smooth Film Flow
Bag former installed skewed? Film feeding like a saw? The culprit is often the gap between the seal jaws and the bag former. The manual specifies 2mm: too close causes drag and wrinkles; too far causes seal misalignment and leaks. This guide walks the 4-step fix: loosen handle A, turn knob, set 2mm, tighten A. Factory pre-adjusted; re-check only after former change.
-
Photoeye (Color-Mark Sensor) Drift: Ultimate Fix — Sensitivity or Position?
Photoeye drift is a "mysterious" VFFS fault: bags cut off-center and the screen shows "color-mark photoeye fault". Based on the manual, this guide separates the two causes — position off vs poor contrast — then gives the 3-step bracket fix: loosen the lock handle, slide the track frame, move the bracket until the photoeye faces the mark; light off means aligned. It also covers film-printing requirements and the right order: check the mark, then distance, sensitivity last.
-
Bag Length Setting Always Off? Time Mode vs Color-Mark Mode Explained (VFFS Guide)
Bag length set at 120 but the bags come out 125? The problem is usually the mode, not the number. In color-mark mode, bag length equals the distance between two register marks, tracked by a photoeye. In time mode, the machine calculates cutting rhythm from delay and action times. When film pulling is unstable, adjust the delay time first — not the bag length. Includes the bag-length range table, a photoeye drift quick-fix table and a shop-floor self-check tip. Save it.
-
Puffed or Flat Bags? One Sponge's Position Decides Inflation vs Exhaust
Want puffed or flat bags? The answer is in one tiny pressure sponge. Per the manual: mount sponges on the upper jaw surface for inflated (puffed) bags; on the lower surface for exhausted (flat) bags. Snacks need cushioning; powders need compactness. Both sponges must match. Clean hot jaws daily to prevent sticking.
-
Why Does Your Temperature Controller Keep Burning Out?
Temperature controllers that keep burning out, heating tubes that burst within months, and a machine frame that gives operators a mild shock are rarely machine-quality problems — in nine cases out of ten they are power connection problems. This article, the 8th of the Vertical Packaging Machine Encyclopedia series, breaks the fatal details of electrical installation into six practical parts.
-
Automatic Granule Bottle Filling Production Line
Tired of low-efficiency manual granule bottling & inconsistent packaging quality? 🤔
Upgrade your food packaging business with our Full Automatic Granule Bottle Filling Production Line! Your one-stop solution for all granular product packaging needs✅
🌰 Widely Compatible with Various Granule Products
Perfect for peanuts, sunflower seeds, tea leaves, nuts, snacks, spices and all kinds of granular materials. Ideal for food factories, snack processing plants and packaging enterprises! -
Automated Chemical-Free Bean Sprout Production Line | Intelligent Physical Regulation Sprouting Equipment
Automated Chemical-Free Bean Sprout Production Line | Intelligent Physical Regulation System
Meta Description：Full automatic bean sprout processing plant with intelligent sealed germination tech, 100% zero additives, only beans & water. Stable high-quality sprouts without lateral roots. Turnkey factory solution for supermarket & wholesale sprout manufacturers. -
Bag-in-Bag Secondary Packaging Machine Video Show – Original Manufacturer Supply
How to pick the right small bag into big bag secondary packaging machine? Check our real customer complete production line case!
Small pouch:100120mm, big bag:200280mm, 3–8 pcs per bag, speed 50 bags/min
Full line: incline elevator + counting combination weigher + working platform + vertical packer + coder + finished conveyor
Seamlessly connect upstream small pouch feeding & downstream auto cartoner -
Double Head Servo Capping Machine | Automatic Linear Bottle Capping Machine Factory
Double head servo capping machine is a high-precision linear automatic capping solution for food, spice, powder, granule, and daily chemical bottling production. Designed with full servo torque control, this automatic bottle capping machine delivers 99.99% capping accuracy, zero cap damage, and stable high-speed output. Widely applied in garlic powder, garlic granule, and spice bottling lines.
-
Accurate Garlic Powder Measuring: Custom Screw & Anti-Blocking Solution for ±1g Precision
Struggle with inconsistent garlic powder dosing, dusting, and material clogging? Our custom garlic powder screw dosing and anti-blocking devices deliver stable 500g±1g accurate measurement for garlic powder filling machine and packaging, realizing reliable high precision powder dosing.: Struggle with inconsistent garlic powder dosing, dusting, and material clogging? Our customized screw and anti-blocking devices deliver stable 500g±1g accurate measurement for garlic powder packaging and filling.
-
Automatic Garlic Powder & Granule Bottling Line Direct Manufacturer
This high-efficiency garlic powder bottling machine supports 1–5 lbs adjustable filling weight and adapts to various custom bottle shapes and gram specifications. With a stable output of1200 bottles per hour, it perfectly meets small-batch diversified orders and large-scale mass production demands.
-
Automatic Bean Sprouts Packaging Machine | Direct Manufacturer with Global Cases
As a leading direct manufacturer of automatic bean sprouts packaging machines, we specialize in turnkey solutions for soybean sprouts, mung bean sprouts, and other strip-shaped fresh produce packaging. With 16 years of R&D and manufacturing experience, our full automatic bean sprouts packaging line has been widely used in sprout production bases, vegetable processing plants, fresh food distribution centers, and wholesale markets worldwide.
-
Automatic Bean Sprout Weighing Packing Machine | Full Automatic Food Packaging Line
High-speed automatic bean sprout packing machine with multi-head weigher, stable weighing, labor-saving, hygienic and fully automatic packaging solution for bean sprout factories.
-
1–3kg Edible Ice Packaging Line Delivered to Uruguay | FY‑L630 VFFS Machine
We delivered a fully automatic 1–3kg edible ice packaging line (FY‑L530) to a top Uruguayan ice producer. Features: hygienic, ±15g accuracy, 8–12 bags/min, 304 stainless steel, low-temp stable. Get your turnkey solution now.
-
Turnkey 1–3kg Edible Ice Packaging Solution Successfully Delivered to Uruguay
-
How to Choose a Reliable 20g Powder Packaging Machine? 5 Key Points from a 20-Year Expert
20g powder packaging machine selection, high precision powder packaging, reliable powder packaging supplier, source manufacturer packaging machine, global powder packaging solution
-
Calculate Your VFFS Machine ROI: How Fast Will You Profit?
Investing in a vertical packaging machine is a big decision—but data shows most businesses see full ROI in 6–12 months.
