FY-430
Technical Parameters
|
Model |
FY-430 |
|
Bag size |
(L) 80-300mm |
|
Film width |
Max.430mm |
|
Film thickness |
0.04-0.10mm |
|
Packing speed |
20-110 bags/min |
|
Air consumption |
0.65Mpa, 0.4m³/min |
|
Packing material |
All laminated film such as PET/PE, PET/AL/PE, Nylon/PE, etc.; PE (confirm when order) |
|
Power supply |
220V/380V 50-60Hz |
|
Power |
2.8kw |
|
Dimension |
L1665 x W1060 x H1500mm |
|
Weight |
350kg |
Product Introduction
- Low investment, high return, high speed and high efficiency.
- PLC full computer control system with human-machine interface and large touch screen for easy operation.
- Servo film feeding system, with servo/pneumatic control for transverse sealing, ensuring accurate positioning and excellent overall performance, which maximizes the reliability and intelligence of the machine.
- Equipped with a metering device, this machine can automatically complete the whole process of feeding, bag making, filling, date printing, inflation (deflation), counting and finished product output.
- Bag styles: The machine can produce pillow bags, vertical bags, punched bags, multi-connected packs and half-punched multi-connected packs according to customer requirements.
